PMF Fabricated Floating/Ladder Traction Bar System - 6.0 Powerstroke (2005-2007)

PMF Fabricated Floating/Ladder Traction Bar System - 6.0 Powerstroke (2005-2007)

Skip to product information
1 of 1

PMF Fabricated Floating/Ladder Traction Bar System - 6.0 Powerstroke (2005-2007)

PMF Fabricated Floating/Ladder Traction Bar System - 6.0 Powerstroke (2005-2007)

SKU PMF-FRD-4001-WO-LB-40

Regular price $ 750.00
Regular price Sale price $ 750.00
Size

Traction Bar System - 4" axle

Description:

   When considering traction bars from both us and other manufacturers there are many things to consider.  There is no one size fits all nor perfect kit for every application.  There are two main designs on the market; ladder bars and anti wrap bars (single bar designs).  Both (properly designed) will work to decrease/prevent axle wrap and wheel hop.  Only a ladder bar style (two mounts on the axle) will actually increase wheel traction by transferring additional weight to the rear axle as it tries to lift the front of the bar.  This style has been popular among drag racers for decades.

   We have taken the traditional ladder bar and taken it to a new level.  Our design has a "floating" shackle on the frame side to allow the suspension to cycle without bind.  This is where our kit gets it name.  With the design of our kit, we eliminate axle wrap, wheel hop, and give your truck a secure planted feeling under acceleration and braking.  This kit will smooth out harsh shifts and help the truck to launch straight.


  This style of bar is best suite for drag race and sled pull type applications.  With the way these bars are designed, they need to sit level to the ground.  Trucks with decent sized lifts would be better suited with our "Single Bar Series" systems as they tuck up to the bottom of the truck tighter and maintain ground clearance.

The triangulated bars are built from 1.5" .120 wall DOM tubing and then gusseted to prevent any unwanted axle movement.  Unlike many other bars of similar design on the market we use a forged poly joint on the axle side and uniball joints on the frame side.  This prevents squeaks, rattles, and premature replacement of associated parts.  Be wary of kits that use heim joints on the axle side.  Over time wear will cause them to creak and clunk.  Dont be fooled by less expensive setups that will leave you with bent or broken bars.

  All bushings supplied are heavy duty poly and grease zerks are included to prevent any squeaks.  Both the front and rear of the traction bar are adjustable to allow you to fine tune the bars even if suspension lift sizes is later changed.

  Our kits will work on both single and dual rear truck applications.

  Special Notes:   Frame will need to be drilled for front traction bar mount.  Additional frame modifications may be needed for the frame mounts depending on skid plate and fuel pump configuration.
